2003-2007 BMW 530i 6 pcs Ignition Coil 3-Blade HYR HYRO51D1
Item#:HYRO51D1
Select your BMW 530i year
Orders ship within 1 business day. Estimated delivery dates apply. See our for details.
3-Year Limited Warranty. Free replacement for defects in materials or workmanship. Misuse or improper installation not covered.
90-Day Hassle-Free Returns on all orders. No return shipping fees when your return meets our Return Policy requirements.
Specifications
Installation
Front Side
Warranty
3-Year
Quantity
A Set of 6
Color
Black
Secondary Resistance(KΩ)
7.8±10%（7.02-8.58）
Primary Resistance(ohms)
2.1±10%（1.9-2.3）
Voltage
12V
Terminal Type
Blade
Terminal Quantity
3
Connector Shape
Triangle
Attachment Method
Bolt On
Insulating Grease Included
Yes
Replaces Part Number
12131712219
12131712223
12137551260
5C1476
UF522
E534A
UF44
UF515
UF-667
UF667
Compatibility
To verify fitmentAdd A Vehicle
| Year | Make | Model | Engine | Series |
|---|---|---|---|---|
| 2011 - 2011 | BMW | 1 Series M | L6 3.0L | E87 |
| 2008 - 2013 | BMW | 128i | L6 3.0L | E87/F20 |
| 2006 - 2010 | BMW | 130i | L6 3.0L | E87 |
| 2008 - 2013 | BMW | 135i | L6 3.0L | E87/F20 |
| 2013 - 2013 | BMW | 135is | L6 3.0L | F20 |
| 2003 - 2005 | BMW | 320i | L6 2.2L | E46 |
| 2006 - 2011 | BMW | 323i | L6 2.5L | E90 |
| 2003 - 2006 | BMW | 325Ci | L6 2.5L | E46 |
| 2003 - 2006 | BMW | 325i | L6 2.5L | E46 |
| 2008 - 2010 | BMW | 325i | L6 2.5L | E90 |
Highlights
Product Description
HYR Ignition Coil is engineered for a sealed design and rapid ignition performance. Each connector’s pins are matched to the exact specification, ensuring direct-fit installation.
Key Features & Benefits
- Powerful output: high-quality copper windings deliver consistent energy to the spark plugs.
- Durable construction: vacuum-poured epoxy resin prevents high-voltage breakdown.
