2012-2019 Nissan NV3500 6 pcs Ignition Coil 3-Blade HYR HYRWVAVS
Item#:HYRWVAVS
Select your Nissan NV3500 year
Orders ship within 1 business day. Estimated delivery dates apply. See our for details.
3-Year Limited Warranty. Free replacement for defects in materials or workmanship. Misuse or improper installation not covered.
90-Day Hassle-Free Returns on all orders. No return shipping fees when your return meets our Return Policy requirements.
Specifications
Installation
Front Side
Warranty
3-Year
Quantity
A Set of 6
Color
Black
Secondary Resistance(KΩ)
14.62±10％（13.16-16.08）
Primary Resistance(ohms)
0.9±10%（0.81-0.99）
Voltage
12V
Terminal Type
Blade
Terminal Quantity
3
Connector Shape
Rectangular
Attachment Method
Bolt On
Insulating Grease Included
Yes
Replaces Part Number
224338J115
224338J11C
224488J100
224488J110
224488J111
224488J115
224488J11C
3340082Z00
3340082Z10
33400-82Z10
6734023
49023
1788296
5C1403
5C1727
C1406
C609M6
COP245
GN10242
IGC0006
UF349
UF-349
Compatibility
To verify fitmentAdd A Vehicle
| Year | Make | Model | Engine | Note |
|---|---|---|---|---|
| 2002 - 2004 | Infiniti | I35 | V6 3.5L | -- |
| 2001 - 2003 | Infiniti | QX4 | V6 3.5L | From 07/2001 |
| 2002 - 2006 | Nissan | Altima | V6 3.5L | -- |
| 2005 - 2019 | Nissan | Frontier | V6 4.0L | -- |
| 2001 - 2001 | Nissan | Maxima | V6 3.0L | -- |
| 2002 - 2008 | Nissan | Maxima | V6 3.5L | From 07/2001 |
| 2003 - 2007 | Nissan | Murano | V6 3.5L | -- |
| 2012 - 2021 | Nissan | NV1500 | V6 4.0L | -- |
| 2012 - 2020 | Nissan | NV2500 | V6 4.0L | -- |
| 2012 - 2019 | Nissan | NV3500 | V6 4.0L | -- |
Highlights
Product Description
HYR Ignition Coil is engineered for a sealed design and rapid ignition performance. Each connector’s pins are matched to the exact specification, ensuring direct-fit installation.
Key Features & Benefits
- Powerful output: high-quality copper windings deliver consistent energy to the spark plugs.
- Durable construction: vacuum-poured epoxy resin prevents high-voltage breakdown.
